A sneaky ebike that's lightweight, powerful and has surprising range. All the on-trail traits of a Santa Cruz combined with the FAZUA RIDE 60 drive unit. 150mm of legendary VPP™ suspension, mixed wheels, and progressive geometry makes the Heckler SL a natural handling trail bike. Just with the added power of an ebike.
A trail bike with hidden superpowers
The Heckler SL's trim weight and the Fazua Ride 60 motor's natural-feeling torque delivery feels like riding a normal mountain bike, just with more punch. The range is similar to the full-power bikes because, even though the battery is smaller, the Ride 60 motor sips energy, and a significantly lighter bike makes the job of propulsion easier
Fast, light or powerful? Choose all three!
With three power modes available at the touch of the ring controller, you choose how much push you want and how much range you get. You can customize your ride modes and access more information via the FAZUA app.
Heckler SL Frame Specifications:
-
Wheel Size: MX
- Max Tyre: 2.6"
- Fork Travel: 160mm
- Fork Axle-to-Crown: 571mm
- Fork Offset: 44mm
- Rear Spacing: 148mm
- UDH Spacing: Yes
- Front Derailleur: No
- Headset: IS41/IS52
- Bottom Bracket: Fazua DU w/e-TOR Spindle
- Max Chainring: 36t
- Brake: PM 200mm
- Max Rotor: 220mm
- Shock Dimensions: 210x55
- Shock Mounting Bushing Front: 30x8
- Shock Mounting Bushing Rear: 30x8
Features:
- C Carbon Frame
- Rockshox Lyrik Base 160mm
- Fox Float Performance Shock
- SRAM NX Eagle, 12spd
- SRAM DB8 hydraulic disc brakes
- SDG Tellis Dropper
- Fazua Ride 60 Drive Unit
- 430Wh Integrated, Removable Battery
Product Code | SC-58-24298-147-5-825-642701-02 |
---|---|
Brand | Santa Cruz |
Gender | Unisex |
Frame | Santa Cruz Carbon C |
Fork | RockShox Lyrik Base, 160mm |
Rear Shock | FOX Float Performance, 210x55 or Fox Float DPS Performance, 210x55 |
Shifters | SRAM NX 12spd |
Derailleur (Rear) | SRAM NX Eagle, 12spd |
Brakes | SRAM DB8 |
Crankset | Praxis eTor AL, 104BCD, 165mm |
Cassette | SRAM PG1230, 12spd, 11-50t |
Chain | SRAM NX Eagle, 12spd |
Hub Front | SRAM MTH 716, 15x110, Torque Cap, 6-Bolt 32h |
Hub Rear | SRAM MTH 746, 12x148, HG, 6-Bolt, 32h |
Rims | WTB ST i30 TCS 2.0 29"/27.5" |
Handlebar | e13 TRS Base |
Stem | e.13 Base |
Headset | FSA IS-2/47/42 ACB or Cane Creek 10 IS Integrated |
Saddle | WTB Silverado Medium, CroMo |
Seatpost | SDG Tellis Dropper, 31.6 |
Pedal | Pedals not included with this bike but can be purchased separately here |
Wheel Size | 29 / 27.5 inch |
Number of Gears | 12 |
Motor | FAZUA RIDE60 |
Battery | FAZUA 430 Wh Integrated Battery |
Ready to ride
Every bike from Start Fitness is fully checked & assembled before despatch and will arrive, almost, ready to ride. Each bike is assembled by one of our CyTech accredited mechanics and then packed into one of our custom boxes.
*This process has a lead time of 2-4 working days.
Unfortunately during peak times this may be slightly delayed. We will however, aim to despatch your bike as quickly as possible. Minimal assembly, with basic tools, is required before you can ride. Assembly tools are not usually included.
Making sure you are home
Once fully checked and boxed, we will contact you to arrange a suitable delivery date when you will be home to take delivery. Our bikes are despatched with a premium delivery service which usually delivers next working day (excludes weekends & bank holidays) for mainland UK orders, it may take slightly longer for some areas, Northern Ireland, Channel Islands and outlying Scottish areas. European bike deliveries usually take approximately one week.
Taking Delivery
Any mechanical or cosmetic issues need to be reported to us within one week of the delivery date. If you do not plan on using the bike straight away, we advise that you remove it from the box and check it over ASAP as we cannot be responsible for any reported issues (other than standard warranty issues) later than one week from the date that the bicycle was delivered.
First Service
After a few weeks of riding (we recommend around 6-8 weeks, regardless of how much the bike has been used), a new bike will need a service to make final adjustments and to re-check all nuts and bolts. This is necessary as the bike goes through a ‘bedding in’ phase, after which, final adjustment may be necessary. We recommend that this is carried out by a CyTech qualified mechanic.
It is important to have these checks carried out to prevent any avoidable problems which may not be covered by warranty and to ensure the smooth running of your bicycle. If you’re local to us, we’re able to offer this first service free of charge* at our Newcastle store (NE1 6JE). You’ll just need to call our workshop on 0191 917 3825 to book your service in, and don’t forget to bring your proof of purchase when you drop the bike off with us.
If you’ve had the bike delivered, it will be your responsibility to ensure a first service is carried out at a trusted bike shop local to you, preferably by a Cytech certified mechanic. Start Fitness are unfortunately not able to cover any costs associated with this service if carried out by another store.
*Please note that this complimentary check-over does not include any labour to replace worn parts or to fit new accessories. All bikes should be delivered to us in a clean and serviceable condition, or a £15 cleaning charge will be payable.
Bike Servicing
Bicycles need to be serviced regularly, as a guideline we would advise on at least one full service per year and/or a standard service twice a year. If the bike is used regularly in adverse conditions, more regular servicing may be required.
