The Merida Reacto has always been a class leading aero bike, combining state of the art aerodynamics with rider comfort.
The 4th generation model is more slippery and beautiful than ever, incorporating wider tyres, much neater cockpit cable integration and a series of incremental improvements to boost performance.
In the world of Pro-Tour racing no area can be ignored. Computational Fluid Dynamics (CFD) calculations were used to model performance in a virtual wind tunnel, guiding the changes which offered the most aerodynamic benefit:
Prototypes were wind tunnel tested following the German TOUR magazine standard, including the ‘moving leg dummy’ test. The Reacto CF5 needs just 209 watts effort for 45 km/h speed, 1 watt faster than its predecessor so it's in the leading group of aero road bikes ever tested by TOUR magazine.
Small details such as integrating the front disc cooler behind the fork and the rear disc caliper in the rear triangle and creating new bolt through axles with the thread integrated into the fork dropout minimise drag and improve aerodynamic performance.
A myriad of small improvements over-compensate for the aerodynamic compromises made to give the Reacto bigger tyres, resulting in the perfect package of comfort, aerodynamic, lightweight and style.
A long string of test wins, perfect scores and awards confirm the successful evolution of the race-proven DNA of the previous model with the latest trends and technologies. Cycling Weekly described it as 'without doubt one of the most complete bikes available on the market', Cyclingnews 'an utterly brilliant and faultless machine' and Cycling Plus were 'hugely impressed'.
All Reacto come with powerful hydraulic disc brakes. Calipers are mounted on the chainstay for better dissipation of braking forces using the flat mount standard for a neat, flush fit. Calipers sit on top of CNC'd aluminium Disc Cooler fins which reduce operating temperatures by up to 35%.
Features:
- Lightweight CF5 carbon aero frameset
- Shimano 105 Di2 12spd Groupset
- Shimano 105 Hydraulic Disc Brakes
- FSA SMR ACR stem with Merida Expert CW handlebar
- Merida S-Flex carbon aero seatpost
- Disc Cooler technology and Wire Port cable integration
- Seatpost integrated rear light
Product Code | P462 |
---|---|
Brand | Merida |
Gender | Unisex |
Frame | CF3 IV - carbon with the same geometry and aeroydanmic profiling as the CF5 IV with a more budget friendly carbon lay up. Tapered headtube, Disc Cooler, BB86 BB standard, 142 x 12mm axle standard. Max tyre clearance 700 x 30c |
Fork | Reacto CF3 IV Disc; full carbon, tapered steerer. Max tyre size: 700 x 30c. Disc cooler technology |
Shifters | Shimano 105 disc Di2 |
Derailleur (Front) | Shimano 105 Di2 |
Derailleur (Rear) | Shimano 105 Di2 |
Brakes | Shimano 105 Hydraulic Disc |
Crankset | Shimano 105; FCR7100, 52-36 tooth chainset. Crank length: 165mm (XXS), 170mm (XS), 172.5mm (S,M), 175mm (L,XL) |
Cassette | Shimano CS-R7101; 11-34 teeth; 12 speed |
Chain | Shimano CN-M6100-12 |
Hub Front | Joytech D981SB; 100x12mm; 28 spokes; Centerlock with Merida Expert TR axle |
Hub Rear | Joytech D872SB; 142x12mm; 28 spokes; Centerlock with Merida Expert SL axle including removable 6/4mm allen key |
Rims | Merida Expert CW; 19mm inner rim width; 30mm rim depth; aluminium; Tubeless ready (tubeless tape and valves not included) |
Tyres | Continental Grand Sport Race; 700 x 28C; Kevlar bead, folding |
Handlebar | Merida Expert CW; aluminium; Width 380mm (XXS), 400mm (XS), 420mm (S,M,L), 440mm (XL) |
Stem | FSA SMR ACR; aluminium; -6 degree rise. Length 90mm (XXS,XS), 100mm (S), 110mm (M) 120mm (L,XL) |
Headset | FSA ACR |
Saddle | Merida Expert SL with V-mount; including Merida minitool |
Seatpost | Merida Team CW; Aero shape; 15mm lay back; Carbon with integrated rear light |
Pedal | Pedals not included with this bike but can be purchased separately here |
Wheel Size | 700c |
Number of Gears | 24 |
